R-8024B

4路模擬量輸出模塊

◆ 分辨率：12 Bits

◆ 輸出類型： V、mA

◆ 量程范圍：V：±10V； mA：±20 mA、4～20 mA

◆ 精度：±0.1% FSR 電流輸出；±0.2% FSR 電壓輸出

◆ 零點漂移：電壓輸出±30μV/℃，電流輸出0.2μA/℃

◆ 溫度漂移：±25ppm/℃

◆ 通道：4個

◆ 與ADAM-4024全兼容，D/A通道無需外配電源

◆ 帶ModBus通訊協議

產品型錄

產品介紹
產品規格
檔案下載

4路模擬量輸出模塊

◆ 分辨率：12 Bits

◆ 輸出類型： V、mA

◆ 量程范圍：V：±10V； mA：±20 mA、4～20 mA

◆ 精度：±0.1% FSR 電流輸出；±0.2% FSR 電壓輸出

◆ 零點漂移：電壓輸出±30μV/℃，電流輸出0.2μA/℃

◆ 溫度漂移：±25ppm/℃

◆ 通道：4個

◆ 與ADAM-4024全兼容，D/A通道無需外配電源

◆ 帶ModBus通訊協議

（本產品新舊包裝混發）
