PCP-CAN20

PC104+總線隔離型雙口CAN接口卡

主要特點
- 能同時操作兩個獨立CAN網絡

- 可達500Kbps的傳輸速率
- 16 MHz CAN控制器頻率

- 確保系統可靠性的1000VDC光隔離保護

- 每個端口可自由選擇IRQ：IRQ3，4，5，6，7，9，10，11，12，15

- 顯示每個端口收/發狀態的LED指示燈

- 直接存儲器映射，可訪問CAN控制器

產品型錄

產品介紹
產品規格
檔案下載

PC104+總線隔離型雙口CAN接口卡

PCP-CAN20是一款連接控制器局域網（CAN）和PC的專用通訊卡。由于帶有內置的CAN控制器PCP-CAN20能夠提供總線仲裁及查錯功能，可以在檢查到錯誤時自動重發數據。這樣大大降低了數據丟失的機率，有效確保了系統的可靠性。此外PCP-CAN20還具有1Mbps的傳輸速率，并且能安裝在通用的PC104+卡槽上。

總線接口	兼容PC104+總線規格
端口	2
協議	CAN2.0 A/B
CAN控制器	SJA1000
CAN收發器	82C251
信號支持	CAN_H, CAN_L
控制器頻率	16MHz
速率	1Mbps 傳輸速率
隔離保護	1000VDC
接口	可接兩個DB9接口
功耗	5V@400A
工作溫度	0℃～65℃
存儲溫度	-25℃～85℃
工作濕度	5～95％RH,無凝結
尺寸	90mm × 96mm
