·CPU | Atmel SAMA5D36 Cortex a5, 536MHz |
·Storage | 512M Nand Flash，256KB SRAM (Save the data one month) |
·Operating system | Linux |
·Real-time clock | enabled |
·Built-in watchdog | enabled |
·COM1 RS | RS-232/485 |
·COM2 | RS-485 |
·COM3 | RS-232 |
·COM4 | RS-232/485 |
·communication protocol | Modbus/RTU and Modbus/TCP |
·I/O capacity | 4 slots(9431/9438)，8 slots(9831/9838) |
·Status display | Power, CPU, Communication and battery |
·CPU power consumption | 3.0W |
Field bus | CAN field, 2 interface, Support 2.0A/2.0B Protocol |
Isolation protection | ·power input | 3000 VDC |
·communication | 2500 VDC(except COM3) |
Ethernet | 1*10/100/1000Mbps, 1*10/100Mbps |
VGA display | ·Resolution | 1024*768 |
Extension | Through 485 extensible 32 slave units of 4/8 slots |
Software support | ·Isagraf Soft logic programming |
·C language programming |
Power | ·Unconditioned +10～+30VDC |
·Reverse power protection |
Mechanical features | ·Coating | KJW plastics, with install accessories |
| ·Plug-in screw terminator | Plug-in screw terminator: diameter of lead 0.05mm2 to 2.5mm2, 1-＃12 or 2- ＃14 to ＃22AWG |
Environment | ·Operating temp | -40～85℃ |
·Storage temp | -40～85℃ |
·Humidity | 5～95 ％non-condensing |
Order information | ·RemoDAQ-9431 | 4 slots Ethernet programmable controller |
·RemoDAQ-9438 | 4 slots Ethernet programmable controller |
·RemoDAQ-9831 | 8 slots Ethernet soft logic controller |
·RemoDAQ-9838 | 8 slots Ethernet soft logic controller |
